Jeio Tech | Hotplate and Magnetic Stirrers Multi type | Multi Position Heated Magnetic Stirrer with PID Control and High Performance BLDC Motor
The Jeio Tech Hotplate and Magnetic Stirrers Multi type, available at Alto Med Supply, is designed for laboratories that require reliable simultaneous stirring and heating for multiple samples.
With up to 15 independently controlled stirring positions on a single heated top plate, this advanced laboratory magnetic stirrer is ideal for research, sample preparation, chemical analysis, and other testing applications that demand consistent conditions across multiple samples.
This multi-position heated stirrer features flexible operation modes that allow users to control single points, multiple points, entire rows, or full columns based on laboratory needs.
The integrated heater and top plate design delivers fast heat transfer and quick heating performance, helping improve laboratory efficiency and productivity.
Its high-performance BLDC motor and powerful magnetic coupling system provide precise, stable, and quiet stirring even when working with viscous media.
The smooth-start function minimizes stir bar decoupling, while the instant stop feature allows quick interruption of stirring operations when needed.
An easy-to-read VFD display, intuitive control panel, and bright LED indicator lamps make operation simple and convenient.
The high heat transfer aluminum top plate ensures even heating and long-lasting durability for daily laboratory use.
For added safety, the unit is designed to protect internal components from accidental spills and includes a non-slip silicone plate mat to help secure containers during operation.
Built-in thermal shutoff and current limit protection provide additional safety and reliable long-term performance.
The Jeio Tech Hotplate and Magnetic Stirrers Multi type is an excellent solution for laboratories seeking efficient multi-sample heating and stirring with advanced control and dependable performance.
Key Features
-
15 Stirring Positions: Supports simultaneous sample mixing.
-
Heating & Stirring: Combines heating and mixing in one unit.
-
Flexible Modes: Supports single, multiple, row, and column stirring.
-
Fast Heating: Delivers quick heat transfer.
-
BLDC Motor: Provides smooth and quiet operation.
-
Magnetic Coupling: Maintains stable stirring performance.
-
Smooth Start: Reduces stir bar decoupling.
-
Instant Stop: Enables quick operation control.
-
VFD Display: Ensures easy monitoring and control.
-
LED Indicators: Show active positions at a glance.
-
Aluminum Top Plate: Improves heating efficiency.
-
Non-Slip Mat: Helps keep containers stable.
-
Spill Protection: Protects internal components.
-
Safety Protection: Includes thermal and current safeguards.
Specifications
| Multi-Position Heated Magnetic Stirrer Specifications |
| Specification |
MS-33MH |
MS-53MH |
| Performance |
| Temperature Range |
Max. 120°C / 248°F |
| Heating Control |
Scale Control |
| Heating Power |
600 W |
1000 W |
| Speed Range |
30 – 2,000 rpm |
| Stirring Control |
PID Feedback Control |
| Stirring Positions |
9 |
15 |
| Stirring Point Distance |
117 × 90 mm / 4.61 × 3.54 in |
| Timer |
1 min. – 99 hr. 59 min. |
| Motor & Safety |
| Motor Type |
BLDC Motor |
| Motor Input / Output (Per Point) |
2.9 W / 1.6 W |
| Max. Stir Bar Size |
Ø8 × 30 mm / 0.31 × 1.18 in |
| Over-Temperature Protection |
Top Plate Protection |
| Over-Current Protection |
Current Limit Protection |
| Maximum Load |
30 kg / 66.14 lbs. |
| Construction & Dimensions |
| Top Plate Material |
Aluminum |
| Top Plate Size (W × D) |
385 × 328 mm
15.16 × 12.91 in |
385 × 493 mm
15.16 × 19.41 in |
| Body Material |
Powder-Coated Steel |
| Body Size (W × D × H) |
395 × 450 × 104 mm
15.55 × 17.72 × 4.09 in |
395 × 614 × 104 mm
15.55 × 24.17 × 4.09 in |
| Net Weight |
10 kg / 22.05 lbs. |
15 kg / 33.06 lbs. |
| Electrical & Ordering Information |
| Electrical Requirements (230V, 50/60Hz) |
4.1 A |
5.8 A |
| Catalog No. (230V) |
AAHK34015K |
AAHK34025K |
| Electrical Requirements (120V, 60Hz) |
8.0 A |
11.2 A |
| Catalog No. (120V) |
AAHK34013U |
AAHK34023U |
Product Manual
User manual for Jeio Tech Hotplate and Magnetic Stirrers Multi type can be found here.
