Jeio Tech | Personal Low Temperature Incubator | With Peltier Technology, Compact Stackable Design and Precise Temperature Control
The Jeio Tech Low Temperature Incubator, available from Alto Med Supply, is a compact and energy-efficient laboratory incubator designed for reliable low temperature incubation and culture applications.
Using advanced Peltier cooling technology, this incubator minimizes vibration and reduces power consumption while delivering stable and precise temperature control for laboratory environments.
Its compact and stackable design helps maximize valuable workspace, making it ideal for laboratories with limited bench space.
The internal air circulation system maintains consistent temperature conditions throughout the chamber, while the sealed inner glass door with silicone packing allows clear sample observation without disturbing internal temperatures.
The magnetic outer door design opens and closes smoothly to help reduce sample disruption during operation.
Durable stainless steel shelves and interior surfaces provide excellent corrosion resistance and simplify cleaning and maintenance.
The Jeio Tech Low Temperature Incubator features advanced microprocessor PID control with auto-tuning and temperature calibration for accurate and stable operation.
Users can conveniently save up to three frequently used temperature settings and use the Wait On/Off timer for automated operation up to 99 hours and 59 minutes.
The incubator also supports PC connectivity for easy operation and data management, while optional LC Connected mobile monitoring with LC Green Box allows users to monitor the unit remotely through a mobile app.
Designed with laboratory safety in mind, the incubator includes a top-rated overheating protection system, over-temperature limit protection, and a controller lock function to help prevent accidental operation changes.
Additional convenience features include temperature sensor disconnection alarms, adjustable internal air circulation speed, and defrost cycle control for dependable long-term performance.
For flexible laboratory applications, the Jeio Tech Low Temperature Incubator includes a programmable 9-step operation system that allows users to customize temperature and time settings for different culture and incubation experiments.
Each step can be programmed for up to 99 hours and 59 minutes, providing reliable and repeatable laboratory process control.
Key Features
-
Compact Design: Saves space.
-
Peltier Cooling: Energy-efficient operation.
-
Uniform Temperature: Maintains stable conditions.
-
Glass Door: Allows sample viewing.
-
Stainless Steel Interior: Durable and easy to clean.
-
PID Control: Ensures accurate temperatures.
-
Temperature Presets: Saves common settings.
-
Programmable Timer: Supports automated operation.
-
PC Connectivity: Enables data management.
-
Adjustable Airflow: Optimizes performance.
-
Remote Monitoring: Optional mobile access.
-
Overheat Protection: Enhances safety.
-
Controller Lock: Prevents setting changes.
-
9-Step Programming: Supports custom protocols.
Specifications
| Specification |
ILP-02 |
ILP-12 |
| Chamber Capacity |
| Volume |
14 L (0.5 cu ft) |
48 L (1.7 cu ft) |
| Temperature Performance |
| Operating Temperature |
5°C–40°C (41°F–104°F) @ 20°C Ambient 10°C–40°C (50°F–104°F) @ 25°C Ambient 15°C–40°C (59°F–104°F) @ 30°C Ambient |
| Temperature Fluctuation @ 25°C |
±0.1°C (±0.18°F) |
±0.1°C (±0.18°F) |
| Temperature Variation @ 25°C |
±0.5°C (±0.9°F) |
±0.4°C (±0.72°F) |
| Heating Time to 40°C |
17 Minutes |
9 Minutes |
| Cooling Time (40°C to 5°C) |
60 Minutes |
60 Minutes |
| Recovery Time @ 25°C |
1.5 Minutes |
1.5 Minutes |
| Interior Dimensions |
| W × D × H |
315 × 200 × 230 mm (12.4 × 7.9 × 9.1 in) |
334 × 334 × 430 mm (13.1 × 13.1 × 17.0 in) |
| Exterior Dimensions |
| W × D × H |
430 × 495 × 400 mm (17.0 × 19.4 × 15.7 in) |
430 × 665 × 620 mm (17.0 × 26.2 × 24.4 in) |
| Shelving Capacity |
| Standard Shelves |
1 |
2 |
| Maximum Shelves |
6 |
13 |
| Maximum Load Per Shelf |
15 kg (33.0 lbs) |
20 kg (44.1 lbs) |
| Weight |
| Net Weight |
27.5 kg (60.6 lbs) |
49 kg (108 lbs) |
| Electrical Requirements |
| 230V, 50/60Hz |
1.8 A |
3.5 A |
| 120V, 60Hz |
3.4 A |
6.7 A |
| Ordering Information |
| Catalog No. (230V) |
AAH24032K |
AAH24042K |
| Catalog No. (120V) |
AAH24033U |
AAH24043U |
Product Manual
User manual for Jeio Tech Personal Low Temperature Incubator can be found here.
