Jeio Tech | Shaking Heating Bath | Reciprocal with Transparent Cover, PID Temperature Control and USB Monitoring
The Jeio Tech Reciprocal Shaking Heating Bath with Transparent Cover, available at Alto Med Supply, delivers precise temperature and shaking control for laboratory incubation, mixing, and testing applications.
Featuring a temperature range from ambient +5°C to 100°C and shaking speeds up to 200 rpm, this laboratory shaking water bath uses advanced PID control and calibration functions to provide accurate and stable performance.
The shaking motion promotes excellent temperature uniformity, while the extended bath height accommodates larger sample volumes, including flasks up to 2.8L.
A transparent gable-style cover helps prevent condensation from dripping onto samples during operation.
Designed for convenience, the unit includes a touch color display, automatic timer, side drain port, and USB connectivity for monitoring and data recording.
Optional mobile monitoring and 21 CFR Part 11 compliant LC DataKeeper integration are also available for advanced laboratory applications.
Built-in safety features include audio and visual alarms, low water protection, heater shutdown, and over-current protection for reliable everyday laboratory use.
Key Features
Temperature Range: Ambient +5°C to 100°C.
Shaking Control: Speeds up to 200 rpm.
PID Control: Stable temperature performance.
Large Capacity: Supports flasks up to 2.8 L.
Touch Display: Easy operation and monitoring.
Programmable Timer: Up to 999 hr 59 min.
USB Connectivity: Supports data logging.
Protective Cover: Reduces condensation.
Mobile Monitoring: Optional remote access.
Safety Protection: Low-water and system alarms.
Specifications
BS2 Series Reciprocal Shaking Water Baths Specifications
Specification
BS2-10
BS2-15
BS2-20
BS2-30
Performance
Bath Volume
17 L (0.6 cu ft)
26 L (0.9 cu ft)
37 L (1.3 cu ft)
55 L (1.9 cu ft)
Temperature Range
Ambient +5°C to 100°C (Ambient +9°F to 212°F)
Temperature Stability @ 50°C
±0.1°C (±0.18°F)
Motion Type
Reciprocal
Shaking Speed
30 – 200 rpm
Stroke Length
25 mm (0.98 in)
25 mm (0.98 in)
30 mm (1.18 in)
30 mm (1.18 in)
Bath Opening & Depth (W × L × D)
Metric
300 × 250 × 235 mm
300 × 370 × 235 mm
300 × 520 × 235 mm
350 × 670 × 235 mm
Imperial
11.8 × 9.8 × 9.3 in
11.8 × 14.6 × 9.3 in
11.8 × 20.5 × 9.3 in
13.8 × 26.4 × 9.3 in
Exterior Dimensions (W × L × H)
Metric
474 × 417 × 426 mm
594 × 417 × 426 mm
746 × 417 × 426 mm
882 × 467 × 426 mm
Imperial
18.7 × 16.4 × 16.8 in
23.5 × 16.4 × 16.8 in
29.4 × 16.4 × 16.8 in
34.7 × 18.4 × 16.8 in
Weight
Net Weight
23 kg (51 lbs)
27 kg (60 lbs)
31 kg (68 lbs)
38 kg (84 lbs)
Electrical Requirements
120V, 60Hz
7.1A
8.8A
N/A
N/A
230V, 60Hz
3.7A
4.6A
8.9A
8.9A
Catalog Numbers
120V Models
AAH44103U
AAH44153U
N/A
N/A
230V Models
AAH44105K
AAH44155K
AAH44205K
AAH44305K
Note: The lowest controllable temperature depends on room and sample temperature variations. Please contact technical support before purchasing.
Technical Standard: Technical data according to DIN 12876.
Bath Fluid: Water
Product Manual
User manual for Jeio Tech Shaking Heating Bath can be found here.
