Priorclave | Smart Front Loading Laboratory Autoclave | EH100–EH320 Smart Series 100–320L High-Capacity Front Load Laboratory Autoclave for Reliable Steam Sterilization
At Alto Med Supply, we offer Priorclave Smart Series front-loading laboratory autoclaves with cylindrical pressure vessels designed for reliable steam sterilization.
The rounded chamber improves steam circulation by eliminating internal corners where cold pockets may form.
This allows steam to distribute evenly throughout the vessel for consistent sterilization results.
These large-capacity Smart Series autoclaves are commonly used in universities, research laboratories, testing facilities, and industrial environments.
They are ideal for sterilizing glassware, culture media, and laboratory equipment while supporting demanding laboratory workflows.
Each system features the programmable Tactrol® control platform for precise automated sterilization cycles.
The chamber and door are constructed from ASME-certified 316L stainless steel for durability and reliability.
Alto Med Supply also offers additional laboratory autoclave configurations to meet different facility requirements.
Key Features
-
Quickseal Single-Action Safety Door: Thermal and pressure safety locks prevent the door from opening when temperatures exceed 80°C or pressure rises above 0.2 bar.
-
Tactrol® 3 Microprocessor Control System: Fully programmable controller allows precise adjustment of sterilization time and temperature with a clear graphic display of cycle status.
-
Automatic Timed Free-Steaming: Automatically releases air before sterilization to improve steam penetration and ensure effective laboratory sterilization.
-
Pre-Cycle Vacuum Technology: Multiple programmed vacuum stages with interspersed heating remove air and allow deeper steam penetration for reliable sterilization.
-
Pulsed Free-Steaming Function: Enhances the efficiency of the pre-vacuum phase to improve sterilization performance.
-
Vacuum Assisted Cooling: Accelerates cooling after sterilization cycles to reduce turnaround time and improve laboratory workflow.
-
Low Water Level Protection Sensor: Detects insufficient water levels and protects the autoclave from operating under unsafe conditions.
-
Post-Cycle Load Drying: Integrated drying function removes residual moisture for faster drying of sterilized loads.
-
Dual Stainless Steel Load Shelves: Two full-width stainless steel shelves provide durable and flexible loading for laboratory equipment and materials.
-
Anti-Bacterial Epoxy Coated Panels: Exterior panels are coated with antimicrobial epoxy that helps prevent growth of bacteria and fungi including MRSA.
-
ASME-Grade Pressure Vessel Warranty: High-quality pressure vessel is insurance approved and backed by a 10-year manufacturer warranty.
-
Manufacturer Service &; Support: Professional technical service and support provided directly by the manufacturer or authorized distributor.
Specifications
Priorclave Smart Series Front-Loading Autoclave Specifications
| Specification |
100L Model |
150L Model |
200L Model |
| Heat Input |
Internal Electrical or Direct Steam Source |
Internal Electrical or Direct Steam Source |
Internal Electrical or Direct Steam Source |
| Chamber Volume |
100 Liters |
150 Liters |
200 Liters |
| Operating Range |
Up to 138°C, 2.4 Bar (280°F / 34 psi) |
Up to 138°C, 2.4 Bar (280°F / 34 psi) |
Up to 138°C, 2.4 Bar (280°F / 34 psi) |
| Loading Format |
Front Loading |
Front Loading |
Front Loading |
| Loading Height |
33.9" |
33.9" |
33.9" |
| Heating Power |
7kW at 30A; 7kW at 15A |
7kW at 30A; 10.5kW at 15A |
7kW at 30A; 10.5kW at 15A |
Chamber Dimensions
(Diameter x Depth) |
19.5" x 21.1" |
19.68" x 29.13" |
19.68" x 40.35" |
Bottom Shelf
Dimensions (W x D) |
14.76" x 21.06" |
14.76" x 29.13" |
14.76" x 40.35" |
Top Shelf
Dimensions (W x D) |
19.09" x 21.06" |
19.09" x 29.13" |
19.09" x 40.35" |
Outside Dimensions
(W x D x H) |
29.93" x 38.89" x 60.19" |
29.93" x 47.83" x 60.19" |
29.93" x 57.83" x 60.19" |
| Weight (Unloaded) |
429.9 lbs |
458.6 lbs |
520.29 lbs |
Minimum Installation
Clearance |
Please allow 19.69" either
side and 11.81"
at the back of the autoclave. |
Please allow 19.69" either
side and 11.81"
at the back of the autoclave. |
61.61" x 36.81" x 24.60"
including door swing |
| Door Swing |
27.55" |
27.55" |
27.55" |
Product Manual
User manual for Priorclave Smart Series Front Loading Autoclave 100L, 150L, and 200L can be found here.
Shipping
- Free curbside delivery (Contiguous United States Only).
-
Made to Order: Please contact us for delivery ETA.
- White glove engineer delivery with assembly and demonstration is available if required. Please contact us for a quote.
- If you require faster shipping or shipping anywhere other than the contiguous United States, please contact us for a shipping quote.
Warranty
This product comes with a 3 year manufacturer's parts warranty.
