Span America | Weigh Scale Bed with Built-In Digital Scale, ReadyWide Expansion and Low Hospital Bed Positioning for Bariatric Patient Care
At Alto Med Supply, we offer the Span America Weigh Scale Bed, an advanced low hospital bed designed to combine accurate patient weight monitoring with exceptional comfort, safety, and clinical functionality.
Built with an integrated digital weigh scale and dual controllers, this innovative medical bed allows caregivers to quickly obtain precise weight readings without transferring the patient, helping improve workflow efficiency and patient care.
The Span America Weigh Scale Bed includes all the premium features of the ReadyWide® bed system, including expandable width capability up to 42 inches for enhanced comfort and accessibility.
Its low-bed design supports safer patient transfers and easier caregiver access, while advanced clinical positioning options provide greater flexibility for patient support and comfort.
Specialized positioning functions, including seated and tilt positions, help accommodate a wide range of patient needs in hospitals, rehabilitation centers, long-term care facilities, and home care settings.
Available with 500 lb or 650 lb safe working load capacities, including a reinforced PLUS model for bariatric care, this adjustable hospital bed is engineered for durability, stability, and long-term performance.
The user-friendly controls and adaptable design help simplify daily caregiving tasks while enhancing mobility and overall patient experience.
The Span America Weigh Scale Bed delivers a comprehensive solution for healthcare providers seeking a reliable hospital bed with built-in scale technology, expandable width adjustment, and advanced patient positioning features in one efficient system.
Key Features
Built-In Digital Weigh Scale: Provides instant, accurate patient weight readings without transfers to improve workflow efficiency in clinical and long-term care settings.
ReadyWide® Bed Expansion to 42 Inches: Two-click system expands bed width for added comfort, easier caregiving, and improved patient access.
Low Hospital Bed Design for Safer Care: Ultra-low height improves patient safety, reduces fall risk, and supports easier entry and exit.
Advanced Clinical Positioning Functions: Includes Comfort Chair, Trendelenburg, and Reverse Trendelenburg positions to support a wide range of patient care needs.
High Weight Capacity Options (Up to 650 lbs): Available in standard 500 lb and PLUS 650 lb models for bariatric and high-acuity patient support.
Smart Stop® Safety Technology: Automatically pauses bed lowering at a safer height to help prevent injuries and improve under-bed awareness.
Enhanced Caregiver Mobility and Ergonomics: Designed for easier bed movement and repositioning, reducing strain on healthcare staff.
3-Position Assist Device for Patient Support: Provides stable support for safer patient transfers and improved mobility assistance.
Under-Bed Lighting and Safety Features: Improves nighttime visibility and enhances overall patient room safety.
Durable, Easy-Clean Medical Construction: Antimicrobial coating and strong ventilated deck design support hygiene, durability, and long-term use.
Specifications
Height Floor to Mattress Support
8-5/8" – 32-1/4" (219 mm – 819 mm)
Deck Angles – Back Elevation
0 – 70°
Deck Angles – Knee Elevation
0 – 30°
Bed Length – Overall Length
82", 86", 90" (2083 mm, 2184 mm, 2286 mm)
Bed Length – Sleep Surface
76", 80", 84" (1930 mm, 2032 mm, 2134 mm) *Requires 4" Bed Extender Kit
Bed Width – Sleep Surface
36", 39", 42" (889 mm, 991 mm, 1067 mm)
Weight of Bed (Without Accessories)
297 lb / 135 kg (Standard model), 301 lb / 137 kg (Plus model)
Safe Working Load
500 lb / 227 kg (Standard model), 650 lb / 295 kg (Plus model)
Warranty
General parts: 1 year
Mechanical: 5 years
Frame: 10 years
Welds: 15 years
Certifications
ANSI/AAMI ES60601-1:2005 – Medical electrical equipment
CAN/CSA-C22.2 No. 60601-1-08 – Medical electrical equipment
CAN/CSA-C22.2 No. 60601-2-52:11 – Medical Beds
CAN/CSA-C22.2 No. 60601-1-2-08 – EMC
